ERCOT transmission map: lines and substations
Explore public transmission lines and substations across the ERCOT footprint, alongside ERCOT's market zones. Open the map to locate a site and inspect the infrastructure around it.
See it on the live ERCOT map, updating as the market publishes.
Explore the ERCOT transmission mapAbout this view
Locate ERCOT transmission infrastructure
The map uses public HIFLD transmission-line and substation records across the ERCOT footprint. Inspect the published names, geometry and voltage fields where available, with ERCOT's market zones for orientation.
Put a site in its grid context
Use the map to compare a site with nearby substations, lines and other available layers. The public inventory describes infrastructure geography; proximity to a line does not establish a connection point, available capacity or an approved interconnection.
Questions
What does this map show?
The transmission lines and substations published in the HIFLD public inventory, drawn across ERCOT's zones. It is geographic reference data — the operational network model, line ratings, and real-time flows stay with ERCOT and the transmission service providers.
Does this cover all of Texas?
The map is framed on the ERCOT grid. Parts of Texas — the far west around El Paso, much of the Panhandle, and parts of East and Northeast Texas — are served by other grids, and the public inventory there belongs to those systems rather than to ERCOT.
Can I tell from the map where a project can interconnect?
It shows where the public network geography runs, which is the starting point. Whether a specific point of interconnection works is settled by ERCOT's generation interconnection process and the transmission service provider.
Will the map open with these layers?
Yes. It opens the live ERCOT workspace with the same transmission, substation, and zone layers and the same viewport shown on this page.
